CF24850BA-3300-3400MHz-A_Rev2

High Performance Bandstop Filter

Electrical Specifications:

- Stop Band Frequency: 3300 - 3400 MHz

- Stop Band Width: 100 MHz

- Stop Band Attenuation: 40dB Min @ 3300 - 3400 MHz

- Pass Band Insertion Loss: 0.5dB Max

- Pass Band VSWR: 2: 1

- Impedance: 50ohm

- IP Protection: IP67 (externally mounted)

- Handling power: 20W

Operating Temperature: -40°C to +60°C

Product Specifications

General Parameters:
Stop Band Frequency: 3300 - 3400 MHz
Stop Band Width: 100 MHz
Stop Band Attenuation: 40 dB min @ 3300 ~ 3400 MHz
Pass Band Insertion Loss: 0.5 dB Max
Pass Band VSWR: 2: 1
Impedance: 50 ohm
Operating Temperature °C: -40 to +60
