Electrical Specifications
- Center Frequency (Fo): 50MHz Fundamental
- Passband @ -3dB: ±7.5 KHz
- Ripple: 1dB max
- Insertion Loss: 2dB max
- Stopband Width@ 18 dB: ±25KHz
- Ultimate Attenuation: 70dB min@ Fo-910KHzn
- Spurious: 10dB min
- Terminating Impedance: 560Ω // 5.0 pF
- Package Type: SMD
Operating Temperature
- -40°C to +85°C
