Electrical Specifications
- Frequency Range: 75MHz
- Passband Width@3db: +/-10KHz Min.
- Ripple: 1.0db Max.
- Stopband@-60db: +/-1000KHz Max.
- Insertion Loss: 4db Max.
- VSWR: 1:2
- Impedance Zin=Zout: 50ohm
- Input Power: 5dbm nominal, 10dbm Max. nondistractive
- Vibration Test: DO-160G Sectio8
Operating Temperature
- -40°C to +85°C
