Electrical Specifications
- Center Frequency (Fo): 1.4 MHz
- Passband Width @ -3 dB: -300 to -3000 Hz min
- Ripple: 1 dB max
- Insertion Loss: 5 dB max at Fo
- Stopband Width@ Fo - 4KHz: 45dB Min
@ Fo + 4KHz: 45dB Min
- Frequency Suppression: 35dB Min
- Ultimate Attenuation: 45dB Min
- Impedance Zin = Zout: 1000 Ohm
Operating Temperature
- -40°C to +70°C
