Electrical Specifications
- Center Frequency (Fo): 10 MHz
- Passband Width @ -3 dB：+/- 500 Hz min
- Ripple: 1.0 dB max @ Fo +/- 50 Hz
- Insertion Loss: 6.0 dB max
- Stopband Width@ - 20dB: +/- 1.2 KHz max
@ - 60dB: +/- 5 KHz
- Ultimate Attenuation: 70 dB min @ Fo +/- 100KHz
- Impedance Zin = Zout: 50 Ohm
- Input Power: -80 to +5dBm
Operating Temperature
- -20°C to +70°C
Storage Temperature
- -40°C to +85°C
