Electrical Specifications
- Center Frequency (Fo): 21.4 MHz
- Passband Width @ -3 dB: +/- 10.5 KHz min
- Ripple: 1 dB max
- Insertion Loss: 4 dB max
- Stopband With: - 60 dB min@ Fo +/-25KHz
- Ultimate: - 60 dB
- Impedance Zin = Zout: 50 Ohms
Operating Temperature
- -40°C to +80°C
Storage Temperature
- -45°C to +85°C
