Electrical Specifications
- Center Frequency (Fo): 20.42 MHz
- Passband Width @ -3 dB: +/- 21 KHz min
- Ripple: 1 dB max
- Insertion Loss: 4 dB max
- Stopband With: - 60 dB min@ Fo +/-80KHz
- 70 dB min@ Fo +/-120KHz
- VSWR: 2.0
- Impedance Zin = Zout: 50 Ohms
Operating Temperature
- -40°C to +80°C
Storage Temperature
- -50°C to +85°C
