Electrical Specifications
- Center Frequency (Fo): 113 MHz
- Passband Width @ -3 dB: 10MHz min
- Ripple: 3 dB max
- Insertion Loss: 7 dB
- Stopband With: - 60 dB min@ Fo +/-31.5KHz
- 8 dB min@ 107.1MHz
- 16 dB min@ 106.1MHz
- 44 dB min@ 103.1MHz
- VSWR: 2.0
- Impedance Zin = Zout: 50 Ohms
- Power Handling: 1W
Operating Temperature
- -40°C to +70°C
