Electrical Specifications
- Center Frequency (Fo): 19.475 MHz
- Passband Width @ -3 dB: +/- 12 KHz max
- Ripple: 1 dB max
- Insertion Loss: 4 dB max
- Stopband With: - 60 dB min@ Fo +/-25KHz max
- Ultimate: - 70 dB min
- VSWR: 2.0
- Impedance Zin = Zout: 50 Ohms
Operating Temperature
- -40°C to +80°C
Storage Temperature
- -50°C to +85°C
