Electrical Specifications
- Center Frequency (Fo): 56MHz
- Passband Width @ -3 dB: +/- 100 KHz min
- Ripple: 1.5 dB max
- Insertion Loss: 5 dB max
- Stopband With: -50 dB min@ Fo +/-500 KHz
- Ultimate: -50 dB from Fo+500 KHz up to 200 MHz
- Spurious: -40 dB min
- Impedance Zin = Zout: 50 Ohms
Operating Temperature
- -40°C to +85°C
