Electrical Specifications
- Center Frequency (Fo): 45MHz
- Passband Width @ -3 dB: +/- 55 KHz min
- Ripple: 1 dB max
- Insertion Loss: 3.5 dB max
- Stopband With: -40 dB min@ Fo +/-300 KHz
- Ultimate: -50 dB
- Impedance Zin = Zout: 50 Ohms
Operating Temperature
- -40°C to +85°C
