Electrical Specifications
- Center Frequency (Fo): 70 MHz
- Passband Width @ -3 dB: ±7.5KHz min
- Ripple: 1 dB max
- Insertion Loss: 3 dB max
- Stopband Width @-25dB: ±25KHz max
- Impedance Zin = Zout: 50 Ohms
- Input level: 10dBm max nondistractive
Operating Temperature
- -20°C to +70°C
