Electrical Specifications
- Center Frequency (Fo): 149.735 MHz - Fundamental
- Passband Width @ -3 dB: ±25 KHz min
- Spurious: 35 dB min
- Insertion Loss: 6.5 dB max
- Stopband Width: 40 dB @ Fo +200 KHz
- Return Loss: 10 dB min @ 80% of bandwidth
- Impedance Zin = Zout: 50 Ohms
- Input Leave: 0 dBm max
Operating Temperature
- -10°C to +55°C
