Electrical Specifications
- Center Frequency (Fo): 65.5 MHz
- Passband Width @ -3 dB: ±17.5MHz min
- Ripple: 1.5 dB max
- Insertion Loss: 2.5 dB max
- Stopband Width: -40dB @ DC-42MHz
-40dB @ 94-300MHz
- VSWR: 1.5@±14MHz
- Impedance Zin = Zout: 50 Ohms
- Group Delay: 100nS
Operating Temperature
- -30°C to +70°C
Storage Temperature
- -40°C to +85°C
