Electrical Specifications
- Center Frequency (Fo): 127.5MHz
- Passband Width @ -3 dB: ±12.5KHz min
- Ripple: 1.0 dB max
- Insertion Loss: 5.0dB max
- Stopband Width@ -50 dB: ±25KHz max
- Spurious: 50dB min
- Impedance Zin = Zout: 50Ohms
Operating Temperature
- -20°C to +70°C
