Electrical Specifications
- Carrier Frequency: 5120KHz
- Passband: shall be no more than 2dB from 5116600Hz to 5119700Hz
- Ripple: 0.5 dB max from 5117200Hz to 5119200Hz
- Insertion Loss: 8dB Max.
- Carrier: 15dB min.
- Stopband: shall be no less than 60dB below Insertion Loss at 5115000Hz and 5120500Hz
- Ultimate Attenuation: 70dB min.
- Impedance Zin = Zout: 1350Ohms±10%
Operating Temperature
- -30°C to +70°C
