Electrical Specifications
- Center Frequency (Fo): 70 MHz
- Passband Width @ -3 dB：+/- 7.5 KHz
- Ripple: 1 dB max
- Insertion Loss: 5 dB max
- Stopband Width@ +/- 20 KHz : 40dB except Spurious
- Spurious: 40dB min
- Ultimate Attenuation: 60dB except Spurious
- Input level - Working / non-damaged: 0 dBm / + 10 dBm
Operating Temperature
- -40°C to +85°C
