Electrical Specifications
- Center Frequency (Fo): 56 MHz - Fundamental
- Passband Width @ -3 dB: ±50 KHz min
- Ripple: 1.5 dB max
- Insertion Loss: 6 dB max
- Stopband Width @ -70 dB min: Fo -200 KHz to Fo +200 KHz
- Spurious: 60 dB min
- Ultimate Attenuation: -60 dB from Fo+200KHz up to 200 MHz
- Impedance Zin = Zout: 50 Ohms
Operating Temperature
- -40°C to +85°C
