Electrical Specifications
- Center Frequency (Fo): 56 MHz
- Passband Width @ -3 dB：+/- 50 KHz min
- Ripple: 1.5 dB max
- Insertion Loss: 5 dB max
- Stopband Width@ - 50dB min: Fo-200KHz to Fo+200 KHz
- Spurious: 40dB min
- Ultimate Attenuation: -50 dB from Fo+200KHz up to 200 MHz
- Impedance Zin = Zout: 50 Ohm
Operating Temperature
- -40°C to +85°C
