ETXO3225I

SMD High Temperature Packaged Crystal Oscillator

Customizable: Yes
ETXO3225I
Data Sheet

Product Specifications

General Parameters:
Sub Category: KHz XO
Type: Extreme Temperature XO
Frequency Min (MHz): 0.032768 MHz
Frequency Max (MHz): 0.032768 MHz
Frequency Stability (ppm): 300 ppm
Output Type: CMOS
Supply Voltage (V): 1.8 V to 5.5 V
Operating Temperature (°C): -55 to +150
Length: 3.2 mm
Width: 2.5 mm
Height: 0.9 mm
