HPXO7500I Series

Extended Temperature SMD Crystal Oscillator

Customizable: Yes

Features and Benefits:

- Frequency Range: 1.0 to 50.0Hz

- Output Waveform: CMOS

- Supply Voltage: 1.8, 2.5, 3.3V

- Frequency Stability: ±50.0ppm

- Aging: ±3.0 ppm first year

- Operating Temperature: -50°C to +100°C

Typical Applications:

- Surveying

- Oceanography

- Telecommunication


Product Specifications

General Parameters:
Type: XO
Supply Voltage (V): 1.8, 2.5, 3.3 V
Output Type: CMOS
Frequency Min (MHz): 1.0 MHz
Frequency Max (MHz): 50.0 MHz
Frequency Stability (ppm): 50.0 ppm
Operating Temperature (°C): -50 to 100
Length: 7.2 mm
Width: 5.0 mm
Height: 1.8 mm
