Electrical Specifications
- Center Frequency (Fo): 45 MHz
- Mode of Oscillation: AT Fundamental
- Passband Width: ±20.500KHz min (6dB)
- Ripple: 2 dB max
- Insertion Loss: 4 dB max
- Stopband Width: ±130.456KHz max (60dB)
±280.456KHz max (70dB)
- Guaranteed Attenuation: 70dB min (f0±280.456KHz~±1000KHz)
- Terminating Impedance: IN: 600Ω OUT: 600Ω
IN Parallel Capacitance: 1.2±0.25pF
- Spurious: 60dB min
- Insulation resistance: More than 500M ohms at DC 100V
- Sealing Test: Reduced Pressure (260mmHg of mercury)
Operating Temperature
- -40°C to +85°C
Storage Temperature
- -40°C to +85°C
