Electrical Specifications
- Center Frequency (Fo): 21.4 MHz
- Mode of Oscillation: AT Fundamental
- Passband Width: ±15KHz min (at 3dB)
- Ripple: 1 dB max
- Insertion Loss: 2 dB max
- Stopband Width: ±50KHz max (at 20dB)
- Attenuation Guarantee: 35 dB min
- Terminating Impedance: IN/OUT: 1500Ω ±1.5pF
- Spurious: 10dB min
Operating Temperature
- -40°C to +85°C
