Electrical Specifications
- Center Frequency (Fo): 45 MHz
- Mode of Oscillation: AT Fundamental
- Passband Width: ±27KHz min (at 3dB)
- Ripple: 1 dB max
- Insertion Loss: 2 dB max
- Stopband Width: ±126.330KHz max (at 20dB)
±276.330KHz max (at 30dB)
- Attenuation Guaranteed : 30dB min (±393.33kHz~±5000kHz)
- Terminating Impedance: IN/OUT: 3000Ω ±0.7pF
- Spurious: 10dB min
Operating Temperature
- -40°C to +85°C
