Features and Benefits
- Frequency range: 125MHz
- Supply voltage: 5.0V
- Steady current: 50mA Max.
- Output waveform: Sinewave
- Frequency stability vs. operating temperature: ±30ppb
- Aging: ±5.0ppb/day
- Phase noise@100KHz: -165dBc/Hz
- Operating temperature: -40°C to +85°C
- Size: 20.5x15.3x9.5mm
- Package type: DIP
Typical Applications
- Portable Wireless Communications Mobile
- Mobile Test Equipment
- Battery Powered Application
- Beacons and Rescue Systems
