Features and Benefits
- Frequency range: 10MHz
- Supply voltage: 5.0V
- Steady Power: 1.5W Max
- Output waveform: Sinewave
- Frequency stability vs. operating temperature: ±10ppb
- Aging: ±50ppb per year
- Phase noise@10KHz: -150dBc/Hz
- Operating temperature: -20°C to +70°C
- Size: 36x27x15mm
- Package Type: DIP
Typical Applications
- Communication System
- Time Synchronization
- RF/Microwave System
