OCXO914S-SMD

Oven Controlled Crystal Oscillator : Surface Mount

Customizable: Yes
OCXO914S-SMD
Data Sheet

Product Specifications

General Parameters:
Type: SMD OCXO
Frequency (MHz): 5 - 40 MHz
Output Type: CMOS
Frequency Stability (ppb): 30 ppb
Supply voltage (V): 3.3 V
Operating Temperature (°C): -40 to +85
Length: 14.3 mm
Width: 9.3 mm
Height: 6.5 mm
