Features and Benefits
- Frequency range: 1KHz-250MHz
- Supply voltage: 3.3V or 5.0V
- Steady current: 15-50mA Max
- Output waveform: HCMOS
- Frequency stability vs. operating temperature: ±0.5ppm
- Aging: ±1.0ppm per year
- Phase noise@100KHz: -145dBc/Hz
- Operating temperature: -40°C to +85°C
- Size: 21.3x11.7x4.5mm
Typical Applications
- UHF Synthesizers
- SATCOM System
- Portable Microwave Applications
