Features and Benefits
- Frequency range: 40MHz
- Supply voltage: 3.3V
- Steady current: 7mA Max
- Output waveform: CMOS
- Frequency stability vs. operating temperature: ±0.5PPM
- Phase noise@10KHz: -150dBc/Hz
- Operating temperature: -40°C to +85°C
- Size: 5.0x3.2x1.85mm
- Package type: SMD
Typical Applications
- Stratum 3
- Femtocell
- Base Stations
