Features and Benefits
- Frequency range: 59.3MHz
- Supply voltage: 3.3V
- Current: 7mA Max.
- Output waveform: Clipped sine
- Frequency stability vs. temperature: ±1.0PPM
- Aging: ±1PPM first year
- Phase noise: -154dBc/Hz@100KHz:
- Operating temperature: -40°C to +85°C
- Size: 5.2x3.4x1.7 mm
Typical Applications
- Portable Wireless Communications
- Mobile Test Equipment
- Radio
- SATCOM System
