Features and Benefits
- Frequency range: 5-52MHz
- Supply voltage: 2.5V or 3.3V
- Steady current: 6.0mA Max
- Output waveform: CMOS or Clipped Sinewave
- Frequency stability vs. operating temperature: ±0.28PPM
- Phase noise@10KHz: -148dBc/Hz
- Operating temperature: -40°C to +85°C
- Size: 7.0x5.0x1.9mm
Typical Applications
- Stratum 3
- Base Stations
