Features and Benefits
- Frequency Range: 25.600MHz
- Supply Voltage: 5.0V
- Steady Current: 3.5mA (Max)
- Output Waveform: Clipped Sinewave
- Frequency Stability vs. Operating Temperature: ±0.25ppm
- Aging: ±1ppm per year
- Phase Noise @ 10KHz: -148dBc/Hz
- Operating Temperature: -40°C to +85°C
- Size: 7.0 x 5.0 x 1.9mm
Typical Applications
- Mobile SATCOM
- Mobile Radio
- Harsh Environments
- Femtocell
