TM2525BM-10MHz-A

GPS Disciplined Oscillator

Features and Benefits

- Built-in GPS receiver module with ±5.0 V for Active Antenna

- Very low power consumption due to its high performance TCXO

- Unmatched cost performance over traditional GPS OCXO reference solutions

- 10MHz CMOS output and 1pps CMOS output

- Enable external 1pps input for discipline

- Discipline to 75ns RMS in phase

- GPS NMEA output

Typical Applications

- Low cost, affordable reference clock

- Test and measurement equipment

Product Specifications

General Parameters:
Product Type: Timing Module
Frequency: 10.0 MHz
Output Waveform: LVCMOS
Operating Temperature: 0 to +60°C
Size: 25.4 x 25.4 x 9.4 mm
