Features and Benefits
- Frequency range: 6-190MHz
- Supply voltage: 3.3V or 5.0V
- Steady current: 30mA Max
- Output waveform: Clipped Sinewave
- Frequency stability vs. operating temperature: ±0.5ppm
- Aging: ±1.0ppm per year
- Phase noise@100KHz: -145dBc/Hz
- Operating temperature: -40°C to +80°C
- Size: 20.2x20.2x10mm
Typical Applications
- UHF Synthesizers
- SATCOM System
- Portable Microwave Applications
