Features and Benefits
- Frequency range: 10-250MHz
- Supply voltage: 2.5/3.3V
- Steady current: 50mA Max
- Output waveform: CMOS
- Frequency tolerance: ±25ppm
- Pulling range: ±50ppm
- Phase noise@1KHz: -105dBc/Hz
- Operating temperature: -40°C to +85°C
- Size: 5.0x3.2x1.25mm
Typical Applications
- High-speed ethernet
- Fiber channel
- HDTV
- ATM
- Set-top box
- WiMAX
- Server
- SAS
- SATA
