Features and Benefits
- Frequency range: 1.544-170MHz
- Supply voltage: 3.3V or 5.0V
- Steady current: 25mA Max
- Output waveform: HCMOS
- Frequency stability vs. operating temperature: ±20ppm
- Aging: ±3.0ppm per year
- Pulling range: ±100ppm
- Operating temperature: -40°C to +85°C
- Size: 7x5x1.7mm
- Package Type: SMD
Typical Applications
- UHF Synthesizers
- SATCOM System
- Portable Microwave Applications
