XO1313-50MHz-A

Crystal Oscillator

Datasheet

Features and Benefits:

- Frequency Range: 50.0 MHz

- Output Waveform: CMOS

- Supply Voltage: 3.3 V

- Frequency Stability: ±25ppm

- Aging: ±5.0 ppm first year

Typical Applications:

- high performance oscillator circuit

- telecommunication

Product Specifications

General Parameters:
Type: XO
Supply Voltage (V): 3.3 V
Output Type: CMOS
Frequency Min (MHz): 50.0 MHz
Frequency Max (MHz): 50.0 MHz
Frequency Stability (ppm): 25.0 ppm
Operating Temperature (°C): -40 to +85
Length: 5.00 mm
Width: 3.20 mm
Height: 2.54 mm
