Features and Benefits
- Frequency range: 100-220MHz
- Output: LVPECL
- Supply voltage: 2.5/3.3V
- Current: 60mA Max.
- Frequency stability vs. temperature: ±20PPM
- Aging: ±3PPM per year
- Operating temperature: -40°C to +125°C
- Size: 2.0x1.6x0.7 mm
Typical Applications
- 400Gbit/800Gbit/1.6Tbit Ethernet, MAN, SONET
- Fiber Channel
- Test Instrumentation
