XO3225AL-76.8MHz-A   New Product

Ultra Compact Oscillator

Features and Benefits

- Frequency Range: 76.8MHz

- Supply Voltage: 3.3V

- Steady Current: 3.8mA Typ

- Output Waveform: CMOS

- Frequency Stability vs. Operating Temperature: ±20ppm

- Operating Temperature: -40°C to +85°C

- Size: 3.20 x 5.00 x 0.75mm

Typical Application

- Ethernet Server, PC, ADC

- Storage Area Network, SONET


Product Specifications

General Parameters:
Type: XO
Supply Voltage (V): 3.3
Output Type: CMOS
Frequency Min (MHz): 76.8
Frequency Max (MHz): 76.8
Frequency Stability (ppm): 20
Operating Temperature (°C): -40 to +85
Length: 3.20
Width: 5.00
Height: 0.75
