XPF7500R-212.5MHz-A

High Stability SMD Crystal Oscillator (XO)

XPF7500R-212.5MHz-A
Datasheet

Features and Benefits:

- Frequency Range: 212.5MHz

- Output Waveform: LVDS

- Supply Voltage: 3.3V

- Frequency Stability: ±25ppm

- Aging: ±2.0 ppm first year

- Phase Noise @ 10KHz: -118 dBc/Hz

Typical Applications:

- telecommunication

- data transfer

Product Specifications

General Parameters:
Sub Category: High Frequency XO
Type: XO
Frequency Min (MHz): 212.5 MHz
Frequency Max (MHz): 212.5 MHz
Frequency Stability (ppm): 25 ppm
Output Type: LVDS
Supply Voltage (V): 3.3 V
Operating Temperature (°C): -40 to +85
Length: 7 mm
Width: 5 mm
Height: 1.8 mm
