DEI5779-21.4MHz

Crystal Filter

Electrical Specifications

- Center Frequency (Fo): 21.4MHz

- Passband Width @ -3 dB: 12.5KHzmin

- Passband Width @ -4 dB: 10KHzmin

- Ripple: 1.5dB max

- Insertion Loss: 4.0dB max

- Stopband Width @ ±30KHz: -70dB min

- Input Power: +3dBm (operative) / +10dBm (damage)

- Ultimate Attenuation: 80dBmin

- Impedance Zin = Zout: 50Ohms

- Operating Temperature: -40°C to +85°C


Product Specifications

General Parameters:
Freq. (MHz): 21.4 MHz
Passband (±Khz): 12.5 KHz
Ripple Max (dB): 1.5 dB
Insertion Loss (dB): 4.0 dB
Stopband (±Khz): ±30 KHz
Temp. Range (°C): -40 to +85
