DEI5855-10MHz

10MHz Crystal Filter

Electrical Specifications

- Center Frequency (Fo):  10.000 MHz

- Passband Width @ -3 dB:  1.5 KHz min

- Ripple:  1.0 dB max

- Insertion Loss: 4.0 dB max

- Stopband Width@ - 60dB:  ±6 KHz max

- Ultimate Attenuation:  70 dB min

- Spurs: 60 dB min

- Input Level: 0dBm

- Impedance Zin = Zout:  50 Ohm

Operating Temperature

- -40°C to +85°C


Product Specifications

General Parameters:
Freq. (MHz): 10.0 MHz
Passband (±Khz): ±1.5 KHz
Ripple Max (dB): 1.0 dB
Insertion Loss (dB): 4.0 dB
Stopband (±Khz): ±6 KHz
Input Level: 0 dBm
Spurious: 60.0 dB
Impedance Zin = Zout: 50 Ohm
Temp. Range (°C): -40 to +85
