Features and Benefits
- Frequency range: 10-52MHz
- Supply voltage: 2.5/3.3V
- Current Consumption: 10mA Max
- Output waveform: Clipped Sine or CMOS/TTL
- Frequency stability vs. operating temperature: ±0.5ppm
- Aging per year: ±1.0ppm Max
- Phase noise@1KHz: -130dBc/Hz
- Operating temperature: -40°C to +85°C
- Size:2.05x1.65x0.8mm
Typical Applications
- Cellular Base Stations
- Instrumentation
- Microwave Applications
- Radar reference
