Features and Benefits
- Frequency range: 24MHz
- Supply voltage: 3.3V
- Steady current: 8mA/Max
- Output waveform: CMOS
- Frequency stability vs. operating temperature: ±0.5ppm
- Aging: ±1.0ppm per year
- Phase noise@100KHz: -152dBc/Hz
- Operating temperature: -40°C to +85°C
- Size: 7x3.2x1.7mm
Typical Applications
- UHF Synthesizers
- SATCOM System
- Portable Microwave Applications
