XO2016BM-ULP-32.768KHz

Ultra-low Power Crystal Oscillator (XO)

Customizable: Yes

Features and Benefits

- Frequency range: 32.768KHz

- Supply voltage: 1.5V/1.8V

- Current: 1.8uA Max.

- Frequency stability vs. temperature: ±25PPM-50PPM

- Aging: ±3PPM per year

- Operating temperature: -40°C to +85°C

- Size: 2.05x1.65x0.75 mm

Typical Applications

- RTC Reference Clock

- Wearable device

- Sport Video Cams

- Ultra-small Notebook PC

- Mobile Phones

- Health and Wellness Monitors


Product Specifications

General Parameters:
Type: XO
Supply Voltage (V): 1.5V, 1.8V
Frequency Min (MHz): 32.768KHz
Frequency Max (MHz): 32.768KHz
Frequency Stability (ppm): 25 ppm to 50 ppm
Operating Temperature (°C): -40 to +85
Length: 2.05 mm
Width: 1.65 mm
Height: 0.75 mm
