XO3225AL-LVDS-100MHz-A   New Product

Standard Frequency Differential Oscillator

Features and Benefits

- Frequency Range: 100MHz

- Supply Voltage: 3.3V

- Steady Current: 47mA Typ

- Output Waveform: LVDS

- Frequency Stability vs. Operating Temperature: ±20ppm

- Operating Temperature: -40°C to +85°C

- Size: 3.20 x 2.50 x 0.75mm

Typical Applications

10GB Ethernet, SONET, SATA, SAS, Fiber Channel, PCI Express, Telecom, Networking, Instrumentation, Servers


Product Specifications

General Parameters:
Type: XO
Supply Voltage (V): 3.3
Output Type: LVDS
Frequency Min (MHz): 100
Frequency Max (MHz): 100
Frequency Stability (ppm): 20
Operating Temperature (°C): -40 to +85
Length: 3.20
Width: 2.50
Height: 0.75
