Features and Applications
- Frequency Range: 10.0 to 125.0MHz
- Supply Voltage: 3.3, 5.0, 12.0V
- Steady Current: 300mA Max
- Output Waveform: Sinewave
- Frequency Stability over Operating Temperature: ±10.0ppb
- Aging: ±50ppb first year
- Operating Temperature: -55°C to +85°C
- Size: 25.6 x 22.4 x 14.0mm
Typical Applications
- SATCOM
- signal analyzer
- microwave
