TCXO5300BT-HS-10MHz_CS-1232

High Stability Low Phase Noise Temperature Compensated Crystal Oscillator (TCXO)

Features and Benefits

- Frequency Range: 10.0MHz

- Supply Voltage: 3.3V

- Steady Current: 7mA max

- Output Waveform: Clipped Sinewave

- Frequency Stability vs. Operating Temperature: ±0.1ppm

- Aging: ±1ppm per year

- Phase Noise @ 100KHz: -152dBc/Hz

- Operating Temperature: -20°C to +70°C

- Size: 5.0 x 3.2 x 1.7 mm

Typical Applications

-SATCOM systems

- mobile radio

- wireless

- test instrumentation


Product Specifications

General Parameters:
Type: TCXO
Frequency Min (MHz): 10.0 MHz
Frequency Max (MHz): 10.0 MHz
Supply Voltage (V): 3.3 V
Output Type: Clipped Sinewave
Frequency Stability (ppm): 0.1 ppm
Operating Temperature (°C): -20 to +70
Length: 5.0 mm
Width: 3.2 mm
Height: 1.7 mm
