TCXO5300BT-HS_CMOS

High Stability Temperature Compensated Crystal Oscillator

Customizable: Yes

Features and Benefits

- Frequency Range: 5.0 to 100.0MHz

- Supply Voltage: 2.5, 2.8, 3.0 3.3V

- Steady Current: 10mA max

- Output Waveform: CMOS

- Frequency Stability vs. Operating Temperature: ±0.05 to 1.0ppm

- Aging: 1ppm per year

- Phase Noise @ 100KHz: -152dBc/Hz

- Operating Temperature: -40°C to +85°C

- Size: 5.0 x 3.2 x 1.7 mm

Typical Applications

-SATCOM systems

- mobile radio

- wireless

- test instrumentation


Product Specifications

General Parameters:
Type: TCXO
Frequency Min (MHz): 5.0 MHz
Frequency Max (MHz): 100.0 MHz
Supply Voltage (V): 2.5, 2.8, 3.0 3.3 V
Output Type: CMOS
Frequency Stability (ppm): 0.05 to 1.00 ppm
Operating Temperature (°C): -40 to +85
Length: 5.0 mm
Width: 3.2 mm
Height: 1.7 mm
