Features and Benefits
- Frequency Range: 100.0MHz
- Supply Voltage: 5.0V
- Steady Current: 40mA(max.)
- Output Waveform: HCMOS
- Frequency Stability vs. Operating Temperature: ±0.5ppm
- Aging: ±1ppm(first year)
- Phase Noise @ 1kHz : -152dBc/Hz
- Operating Temperature: -40°C to +85°C
- Size: 14.4 x 9.5 x 6.2mm(Max)
Typical Applications
- Land Mobile and Portable Radio
- Test and Measurement
- Wireless Communications
- Low Noise Synthesizer Reference
